GSO 8x50mm Right Angle Correct-Image Finder with Bracket
Contiguous US Customers:
All items we sell ship for free within the Contiguous US. Shipping will be via the cheapest shipping method which will vary depending on the items in your order. During checkout, you may also be shown other optional faster shipping choices.
US Customers in Hawaii and Alaska:
Free shipping applies to almost all products. A few large telescopes and mounts are excluded from this free shipping offer. For these items, please contact us to obtain a shipping quote before you check out using the online shopping cart.
International Customers:
Free shipping does not apply to international orders. During check-out, you will be presented with several shipping choices and costs. However, the export of some items may be restricted outside the US due to size or manufacturer restrictions.
Quick Overview
- Right-angle 8x50 finder makes it easier to hunt faint objects without back and neck strain
- Large 50 mm aperture lets you star hop using fainter stars and see many deep-sky objects directly
- Correct-image orientation shows a view of the sky that matches most star charts
- Generous 5.4 degree field of view makes it easy to pick out fainter guidepost stars
- Includes bracket, dovetail base (must be selected while ordering), and dew shield
- Available in white, black, or silver-grey
Product Details
Most telescopes come with a small, straight-through finder telescope. But many astronomers prefer the use of larger, right-angle finders that offer many more advantages. With a 50mm finder, you can hunt down fainter objects that you would not see in smaller 24mm or 30mm stock finders. "Correct Image" finders present a view that matches the orientation of the sky or the orientation of the stars in star charts. And, perhaps most importantly, your back and neck will thank you for using a "Right-Angle" finder and no longer subjecting them to various contortions at the telescope.
So if you are looking to upgrade your stock finder, GSO's high quality 8x50 right angle finder may be just what you need. It features a multi-coated 50mm achromatic objective, an Amici prism that provides a non-inverted, non-reversed correct-image, and single eyepiece cross-hairs that allow for precise centering of faint objects. The field of view is a generous 5.4 degrees.
The finder comes with a bracket and a dovetail base (you must select one of the finder bases from the drop down list above while ordering or it will not be included). The bracket has 2 nylon thumbscrews and one spring-loaded screw for quick and easy alignment of the finder with your telescope. The diagonal and eyepiece are not removable, changeable or rotatable. The finder comes with two protective end caps for the objective and the eyepiece.
This GSO finder telescope is available in a choice of white, black or silver/gray tube (The photo above shows the silver model). The dewshield, diagonal and eyepiece are black in all three models. The finder is easily focusable from the objective end by turning the objective assembly and locking focus using the focus lock ring just behind the dewshield. You may recognize these as the same finders sold by some other big name companies for a lot more.
Total Finder Weight = 18.4 oz (OTA = 11.5 oz, Bracket = 5.5 oz, Dovetail Base = 1.4 oz)
Tube Diameter = 53mm (2.09")
Dewshield Diameter = 58mm (2.28")
Tube Length (White/Black/Silver Section) = 86mm (3.39")
Total Finder Length = 205mm (8.07")
Additional Information
Telescope Mounting and Dovetail Base Choices
You can just purchase the finder with the bracket or also select of one of several optional bases for your telescope (see the drop-down list above for available choices that are in stock). For details of each base, including dimensions and specifications, please see the links below.
We cannot comment on compatibility of any of these bases with your specific telescope. Please use the detailed dimensions provided in the individual descriptions below to make this determination yourself.
- Universal Dovetail Mounting Base (Vixen/Orion/Synta/GSO Type) - Model FURB
- SCT Dovetail Mounting Base - Model SCTFURB
- Dovetail Mounting Base for GSO Crayford Focuser with M4 Mounting Screw - Model CFURB
- Deluxe Dovetail Mounting Base with Cross Slot - Model XFURB (please note that the notch on this item is a little smaller than the corresponding part on the GSO finder stalk, with the result that the finder bracket will stick out of this base on one side by about 3mm).
If you intend to use the included finder bracket with your own dovetail base/shoe or with one already molded into your focuser housing, here are the "foot" dimensions of the bracket so that you can check compatibility with your "shoe."
- Maximum width at bottom: 30.7mm
- Maximum width at top: 23mm
- Height: 9.9mm
Other Information
- Country of Manufacture: Taiwan
