APM 60mm f/3.8 Right Angle Correct Image Finder with 1.25" Prism Diagonal
This item has been discontinued by Agena and we no longer offer this.
Stock count is accurate & shown in real time.
- This item is out of stock.
- Sign up for back-in-stock alerts to be notified when this item becomes available (account login required).
- This item is out of stock.
- Sign up for back-in-stock alerts to be notified when this item becomes available (account login required).
APM Finderscope 60 mm 90° erect image
The high quality APM 60 mm finderscope with a new larger Vixen/Synta-style base with wider contact surface (see additional details below). The included 90° prism provides a correct (upright and unreversed) image. You can also use also many 1.25" eyepieces with this finder - e.g. our optional cross hair eyepieces - or you can use it as a small guiding scope. Note, however, that not all eyepieces might be able to reach focus. The optics and the prism are multicoated.
Delivery contains:
- Finderscope 60 mm
- Finder bracket with Vixen/Synta-syle base
- 1.25" 90° erect image prism diagonal
Specifications:
- Connection to eyepiece: 1 1/4"
- Connection to telescope: Finder bracket with Quick Clamp
- Coating: Fully multicoated
- Housing material: Aluminum
- Aperture: 60 mm
- Magnification: Differs with choosen optional eyepiece
- Lenses: 2 Lenses
- Optical design: Achromat
- Type of viewfinder: 90° Finderscope
- Focal length: 228 mm
- Length: 240 mm
- Diameter: 63 mm
- Accessory: incl. Bracket and Quick Clamp
- Weight: 28.4 oz.
Agena Note: The finder base included with this item is the same one as our XFURB base. Please review the details at this link to see if this included base with fit on your telescope or not. In most cases, please be prepared to provide your own machine screws to mount this on your telescope as the included screws may or may not work for your set-up.
