Baader 2" 90° Star Diagonal with Carl Zeiss Prism
This item is discontinued by the manufacturer and is no longer available.
Stock count is accurate & shown in real time.
- This item is out of stock.
- Sign up for back-in-stock alerts to be notified when this item becomes available (account login required).
- This item is out of stock.
- Sign up for back-in-stock alerts to be notified when this item becomes available (account login required).
Availability: Item has been discontinued and is no longer available.
Baader Planetarium's 2" 90-deg prism diagonal features a premium quality Zeiss prism housed in a precision CNC machined Baader diagonal body. The Zeiss prism has acclaimed T-coatings for obtaining the highest image definition.
The 2" eyepiece holder features a brass compression ring and dual locking thumbscrews. 2" nosepiece is threaded to accept standard 2" astronomy filters (M48x0.75). Diagonal weight = 22.9oz.
On the eyepiece side, the 2" eyepiece holder can be unscrewed. This will expose an inverter ring with an SCT male thread (2" x 24TPI). Removal of this inverter ring then exposes an SCT female thread on the diagonal body. On the telescope side, the nosepiece can also be unscrewed, exposing SCT female threads on the housing. Hence, this diagonal can be closely coupled with an SCT telescope (using the optional SCT lockring) to provide the shortest physical connection for fork-mounted telescopes with limited base clearance. It can also be used with a variety of other Baader T-2 system components (sold separately) for various adaptations.
Baader part #: PRISM-2 or 2406010
