Baader 3.5nm Ultra Narrowband H-Alpha Filter - 1.25"
This item is discontinued by the manufacturer and is no longer available.
Stock count is accurate & shown in real time.
- This item is out of stock.
- Sign up for back-in-stock alerts to be notified when this item becomes available (account login required).
- This item is out of stock.
- Sign up for back-in-stock alerts to be notified when this item becomes available (account login required).
- Precision grade enforced H-alpha filter for f/10 to f/3.5 optical systems
- Opens up the extremely narrow 3,5nm H-alpha world
- This enforced contrast results in even fainter stars, providing more signal of faintest nebulae detail
- Manufacturing such ultra-narrow filter does require extreme coating homogeneity and very high CWL precision, which these filters are designed for. CWL= Center-wavelength / FWHM= full width half maximum.
Note: In general this DeepSky Ultra-Narrowband H-alpha Filter is not suitable for solar observation. The Halfbandwidth of 3,5nm equals 35 Ångstroem, high-quality H-alpha solar filter from SolarSpectrum start at 0.8 Ångstroem. At favorable conditions experiments might still be possible, although at lesser quality.
Specifications:
- Manufacturer: baader Planetarium
- Sku (#): 2459451
- Weight (kg): 0.066
- Colour: black
- Transmission Range: h-alpha
- Filter Thickness (without Cell): 2 Mm
- Hbw (halfbandwidth): 3,5 Nm
- Cwl (central Wavelength): 656,3 Nm
- Ar-coating: dielectrically Coated, Planeoptically Polished
- Special Features: enforced Narrowband
- Filter Size: 1 25 Inch
- Filter Usage: ccd, Deep Sky, H-alpha
- Filter Mounted: mounted (lpfc 6mm)
- Type Of Filter: narrowband
- Single Or Set?: single Filter
- Filter Shape: round
Manufacturer part number: FHALNU-1 or 2459451
WARNING: This filter is not designed for solar observation. NEVER use these filters for observing or imaging the Sun, or permanent eye and equipment damage will result.
Other Information
- Country of Manufacture: Germany
