HoTech SCA 1.25" Reflector Mirror for Advanced CT Laser Collimator
Stock count is accurate & shown in real time.
- This item is out of stock.
- Sign up for back-in-stock alerts to be notified when this item becomes available (account login required).
- This item is out of stock.
- Sign up for back-in-stock alerts to be notified when this item becomes available (account login required).
Contiguous US / Lower 48:
Free shipping applies to orders over $50 using our chosen carrier/method. Faster paid options are available at checkout.
Alaska, Hawaii & US Territories:
Free shipping applies to many—but not all—products. Enter your ZIP code in cart or upon checkout to confirm options and costs.
International:
International orders do not qualify for free shipping. Shipping, duties, brokerage, tariffs, and taxes are the customer’s responsibility. Some items may be restricted due to export, size, or manufacturer limitations.
Precision retro reflector mirror on Self-Centering Adapter for Advanced CT Laser Collimator
- SCA Provides 360 deg. rubber square rings contact for the most secure and reliable adaption in your focuser
- SCA Eliminates Drawtube/Visual Back Slop
- SCA Eliminates unstable locking from thumbscrew or unified compression ring
- SCA Accepts the Imperfection of a Drawtube/Visual Back
- Short SCA Profile Prevents Oscillation
- SCA Damps Vibration
- Double-pass the lasers from the Advanced CT Laser Collimator for higher alignment accuracy
Mirror Specifications:
- Type: Plano-Flat Laser Mirror
- Material: BK7A
- Surface Flatness: λ/8 @ 650nm
- Coating : S1, Aluminum, R>98% for random polarization. Uncoated transparent on S2
Mirror Position (measured from drawtube shoulder to the first surface of the mirror):
- 0.59"/15mm
Dimensions:
- 2" SCA Reflector Mirror: 2"/55mm dia. x 6.25"/159mm (L)
- 1.25" SCA Reflector Mirror: 1.25"/31.75mm dia. x 4"/102mm (L)
Weight:
- 2" SCA Reflector Mirror: 3 oz.
- 1.25" SCA Reflector Mirror: 1.86 oz.
Other Information
- Country of Manufacture: China
