Meade LightBridge Plus 10" f/5 Truss Tube Dobsonian Telescope - Base
This item is discontinued by the manufacturer and is no longer available.
Stock count is accurate & shown in real time.
- This item is out of stock.
- Sign up for back-in-stock alerts to be notified when this item becomes available (account login required).
- This item is out of stock.
- Sign up for back-in-stock alerts to be notified when this item becomes available (account login required).
- 10" (254mm) Newtonian Reflector
- 1270mm Focal Length, f/5
- 2" 2-Speed (10:1) Rack & Pinion Focuser
- 2" Series 4000 26mm Eyepiece Included
- Open Truss Design For Ultra Portability
- Dobsonian Base with No Tool Assembly
Meade’s LightBridge Series continues its legacy with Meade's LightBridgePlus Series Telescopes. The LightBridgePlus Telescopes have a modern, sleek design that incorporates a no-tool assembly build. These telescopes have a large light-gathering capability to provide bright, clear images when viewing deep-space objects such as galaxies, nebulae, planets, and much more.
If you’ve ever wanted a large aperture telescope but were unable to have the ability to move it around on your own, Meade’s LightBridge Plus Telescopes are here to make it practical. This open truss design allows for increased portability over standard solid-tube designs and is able to provide easy setup and teardown for a large aperture telescope.
The redesigned Dobsonian base has a no-tool assembly and provides improved stability. Includes premium features such as roller bearings, a hand-adjustable variable tension brake for smooth and stable movement, and a mounted eyepiece holder that can carry (1) 2” and (3) 1.25” eyepieces for your convenience.
The LightBridge Plus Series Telescopes feature an upgraded 2”, 2-speed Rack and Pinion Focuser. The Rack & Pinion design includes a 10:1 fine focus knob for precise focusing and includes a Vernier scale with millimeter markings on the drawtube to assist with focusing accuracy.
Included with the LightBridge Plus Telescopes is a 3-element, fully multi-coated 2” Series 4000 26mm Eyepiece - providing a 56 degree apparent field of view - and an aluminum Red-Dot Viewfinder. Also included is Meade’s AutoStar Suite Astronomer Edition - displaying more than 15,000 celestial wonders, this software allows you to view the night sky, constellations, planet positions and more from any location.
The LightBridge Plus Series provides high-quality Meade® optics, ultra-portability, and remarkable performance for one affordable price. Get the aperture you’ve always wanted and open the doors to a whole new universe with Meade’s LightBridge Plus.
Specifications:
- Series: LightBridge Plus Telescopes
- UPC: 709942999341
- Warranty: 1 Year
- Experience Level: Intermediate
- Clear Aperture: 10" (254mm)
- Optical Design: Newtonian Reflector
- Focal Length: 1270mm
- Focal Ratio: f/5
- OTA Cooling Fan: Yes
- Viewfinder: Metal Red-Dot Viewfinder
- Eyepiece: 2" Series 4000 26mm
- Focuser Mechanism: 2", 2-Speed (10:1) Rack & Pinion Focuser
- Assembled Product Dimensions: 23.6" x 51.5" (600mm x 1308mm)
- Assembled Product Weight: 71 lbs.
Product carries full one year Meade factory limited warranty (within US/Canada only).
Other Information
- Country of Manufacture: China
