QHY 268M Pro 26 MP APS-C CMOS Cooled Astronomy Camera - Professional Monochrome Version
- This item is out of stock.
- Sign up for back-in-stock alerts to be notified when this item becomes available (account login required).
Stock count is accurate & shown in real time.
- This item is out of stock.
- Sign up for back-in-stock alerts to be notified when this item becomes available (account login required).
- This item is out of stock.
- Sign up for back-in-stock alerts to be notified when this item becomes available (account login required).
Contiguous US / Lower 48:
Free shipping applies to orders over $50 using our chosen carrier/method. Faster paid options are available at checkout.
Alaska, Hawaii & US Territories:
Free shipping applies to many—but not all—products. Enter your ZIP code in cart or upon checkout to confirm options and costs.
International:
International orders do not qualify for free shipping. Shipping, duties, brokerage, tariffs, and taxes are the customer’s responsibility. Some items may be restricted due to export, size, or manufacturer limitations.
QHY268M Pro I is a scientific CMOS camera specially designed for scientific using with advanced qualities and functions.With a SONY IMX571 APS-C format CMOS sensor inside. 26mega pixels, Back-illuminated, native 16BIT ADC. QE is up to 91% and readout noise is as low as 1.1e Even with a 3.76um pixel size, it has a big full-well up to 75ke.
It has extremely low thermal noise 0.0005e/pixel/sec @ -20C, ZERO amplifier-glow performance, It has a maximum frame rate of 6.8FPS@16bit full resolution. QHYCCD IMX571.SONY IMX571/16bit/26Mpixels/BSI/APS-C Format. QHY268PRO has both USB3.0 and 2*10Gbps optical fiber interface. It has a 2GB big DDR3 memory buffer. It has the 6pin GPIO port support complex Trig-In and Trig-Out signal. It can connect with QHY GPS-BOX to get the high-precision GPS timestamp onto the image head.
For full product description, visit the manufacturer's site
QHY268PRO is a cooled scientific CMOS camera with a SONY IMX571 APS-C format CMOS sensor inside. 26mega pixels, Back-illuminated, native 16BIT ADC. QE is up to 91% and readout noise is as low as 1.1e Even with a 3.76um pixel size, it has a big full-well up to 75ke. It has extremely low thermal noise 0.0005e/pixel/sec @ -20C, ZERO amplifier-glow performance, It has a maximum frame rate of 6.8FPS@16bit full resolution.
QHY268PRO has both USB3.0 and 2*10Gbps optical fiber interface. It has a 2GBytes big DDR3 memory buffer. It has the 6pin GPIO port support complex Trig-In and Trig-Out signal. It can connect with QHY GPS-BOX to get the high-precision GPS timestamp onto the image head.
QHY268PRO has both monochrome version and color versions. QHYCCD also supplies the water cooling version. (Water cooling version is a customized version, needs to be pre-ordered).
The QHY268PRO supports the Trig in/out function and GPS function. There is a 6pin GPIO socket on the camera backside. It can be configured into different modes. QHY600PRO also can be customized as the user requests to meeting more complex timing by re-programming the FPGA.
More information on the manufacturer's website
Other Information
- Country of Manufacture: China
For full product description, visit the manufacturer's site
QHY268PRO is a cooled scientific CMOS camera with a SONY IMX571 APS-C format CMOS sensor inside. 26mega pixels, Back-illuminated, native 16BIT ADC. QE is up to 91% and readout noise is as low as 1.1e Even with a 3.76um pixel size, it has a big full-well up to 75ke. It has extremely low thermal noise 0.0005e/pixel/sec @ -20C, ZERO amplifier-glow performance, It has a maximum frame rate of 6.8FPS@16bit full resolution.
QHY268PRO has both USB3.0 and 2*10Gbps optical fiber interface. It has a 2GBytes big DDR3 memory buffer. It has the 6pin GPIO port support complex Trig-In and Trig-Out signal. It can connect with QHY GPS-BOX to get the high-precision GPS timestamp onto the image head.
QHY268PRO has both monochrome version and color versions. QHYCCD also supplies the water cooling version. (Water cooling version is a customized version, needs to be pre-ordered).
The QHY268PRO supports the Trig in/out function and GPS function. There is a 6pin GPIO socket on the camera backside. It can be configured into different modes. QHY600PRO also can be customized as the user requests to meeting more complex timing by re-programming the FPGA.
More information on the manufacturer's website
| Manufacturer | QHYCCD |
|---|
QHY268M Pro I is a scientific CMOS camera specially designed for scientific using with advanced qualities and functions.With a SONY IMX571 APS-C format CMOS sensor inside. 26mega pixels, Back-illuminated, native 16BIT ADC. QE is up to 91% and readout noise is as low as 1.1e Even with a 3.76um pixel size, it has a big full-well up to 75ke.
It has extremely low thermal noise 0.0005e/pixel/sec @ -20C, ZERO amplifier-glow performance, It has a maximum frame rate of 6.8FPS@16bit full resolution. QHYCCD IMX571.SONY IMX571/16bit/26Mpixels/BSI/APS-C Format. QHY268PRO has both USB3.0 and 2*10Gbps optical fiber interface. It has a 2GB big DDR3 memory buffer. It has the 6pin GPIO port support complex Trig-In and Trig-Out signal. It can connect with QHY GPS-BOX to get the high-precision GPS timestamp onto the image head.
For full product description, visit the manufacturer's site
QHY268PRO is a cooled scientific CMOS camera with a SONY IMX571 APS-C format CMOS sensor inside. 26mega pixels, Back-illuminated, native 16BIT ADC. QE is up to 91% and readout noise is as low as 1.1e Even with a 3.76um pixel size, it has a big full-well up to 75ke. It has extremely low thermal noise 0.0005e/pixel/sec @ -20C, ZERO amplifier-glow performance, It has a maximum frame rate of 6.8FPS@16bit full resolution.
QHY268PRO has both USB3.0 and 2*10Gbps optical fiber interface. It has a 2GBytes big DDR3 memory buffer. It has the 6pin GPIO port support complex Trig-In and Trig-Out signal. It can connect with QHY GPS-BOX to get the high-precision GPS timestamp onto the image head.
QHY268PRO has both monochrome version and color versions. QHYCCD also supplies the water cooling version. (Water cooling version is a customized version, needs to be pre-ordered).
The QHY268PRO supports the Trig in/out function and GPS function. There is a 6pin GPIO socket on the camera backside. It can be configured into different modes. QHY600PRO also can be customized as the user requests to meeting more complex timing by re-programming the FPGA.
More information on the manufacturer's website
Other Information
- Country of Manufacture: China
| Manufacturer | QHYCCD |
|---|
