Sky Rover 1x Flattener for 102GPS Telescope
Stock count is accurate & shown in real time.
- This item is out of stock.
- Sign up for back-in-stock alerts to be notified when this item becomes available (account login required).
- This item is out of stock.
- Sign up for back-in-stock alerts to be notified when this item becomes available (account login required).
Contiguous US / Lower 48:
Free shipping applies to orders over $50 using our chosen carrier/method. Faster paid options are available at checkout.
Alaska, Hawaii & US Territories:
Free shipping applies to many—but not all—products. Enter your ZIP code in cart or upon checkout to confirm options and costs.
International:
International orders do not qualify for free shipping. Shipping, duties, brokerage, tariffs, and taxes are the customer’s responsibility. Some items may be restricted due to export, size, or manufacturer limitations.
Sky Rover Optics 1x Field Flattener for 102GPS Telescope
Sky Rover's new 1x Field flattener for 102GPS adopts M63X1 front threads and M48X0.75 rear threads, which meet the illumination requirements of full-frame photography. Considering the use of CCD and OAG, the shell can be removed to use, which can have longer work distance to satisfy the use of filter wheel/OGA/CCD.
Specifications
- Model: 1x field flattener for 102GPS
- Magnification: 1x
- Objective Interface: M63X1
- Ocular Interface: M48X0.75
- Filter Threads: M48X0.75
- Back Focus: 55mm
- Net Weight: 400g
Important Diagrams
Back Focus (55mm)
Connection
- Removing the adapter at the end
- Installing filter
- Screwing adapter into flattener
Full frame camera will be with light vignetting when install inner 2" filter
Camera Connection
①1x flattener ②Filter ③Adaptor (M48x0.75 thread) ④SLR mount (M48 T) ⑤SLR ⑥CCD mount ⑦CCD
OAG Connection
①1x flattener ②Filter ③Adapter (M48x0.75 thread) ④M48 adapter ⑤OAG ⑥Filter wheel ⑦CCD
Other Information
- Country of Manufacture: China
Sky Rover Optics 1x Field Flattener for 102GPS Telescope
Sky Rover's new 1x Field flattener for 102GPS adopts M63X1 front threads and M48X0.75 rear threads, which meet the illumination requirements of full-frame photography. Considering the use of CCD and OAG, the shell can be removed to use, which can have longer work distance to satisfy the use of filter wheel/OGA/CCD.
Specifications
- Model: 1x field flattener for 102GPS
- Magnification: 1x
- Objective Interface: M63X1
- Ocular Interface: M48X0.75
- Filter Threads: M48X0.75
- Back Focus: 55mm
- Net Weight: 400g
Important Diagrams
Back Focus (55mm)
Connection
- Removing the adapter at the end
- Installing filter
- Screwing adapter into flattener
Full frame camera will be with light vignetting when install inner 2" filter
Camera Connection
①1x flattener ②Filter ③Adaptor (M48x0.75 thread) ④SLR mount (M48 T) ⑤SLR ⑥CCD mount ⑦CCD
OAG Connection
①1x flattener ②Filter ③Adapter (M48x0.75 thread) ④M48 adapter ⑤OAG ⑥Filter wheel ⑦CCD
| Manufacturer | Sky Rover |
|---|
- 1x Flattener for 102GPS
- 1x M48 Adapter
Sky Rover Optics 1x Field Flattener for 102GPS Telescope
Sky Rover's new 1x Field flattener for 102GPS adopts M63X1 front threads and M48X0.75 rear threads, which meet the illumination requirements of full-frame photography. Considering the use of CCD and OAG, the shell can be removed to use, which can have longer work distance to satisfy the use of filter wheel/OGA/CCD.
Specifications
- Model: 1x field flattener for 102GPS
- Magnification: 1x
- Objective Interface: M63X1
- Ocular Interface: M48X0.75
- Filter Threads: M48X0.75
- Back Focus: 55mm
- Net Weight: 400g
Important Diagrams
Back Focus (55mm)
Connection
- Removing the adapter at the end
- Installing filter
- Screwing adapter into flattener
Full frame camera will be with light vignetting when install inner 2" filter
Camera Connection
①1x flattener ②Filter ③Adaptor (M48x0.75 thread) ④SLR mount (M48 T) ⑤SLR ⑥CCD mount ⑦CCD
OAG Connection
①1x flattener ②Filter ③Adapter (M48x0.75 thread) ④M48 adapter ⑤OAG ⑥Filter wheel ⑦CCD
Other Information
- Country of Manufacture: China
| Manufacturer | Sky Rover |
|---|
- 1x Flattener for 102GPS
- 1x M48 Adapter
Sky Rover 1x Flattener for 102GPS Telescope
