Sky-Watcher EQ8-Rh Observatory-Class Computerized GoTo Telescope Mount Head with Counterweights (No Pier Tripod)
- This item is currently on backorder from the manufacturer.
- Orders are fulfilled in the order they are received once inventory arrives.
Stock count is accurate & shown in real time.
- This item is out of stock.
- Sign up for back-in-stock alerts to be notified when this item becomes available (account login required).
- This item is out of stock.
- Sign up for back-in-stock alerts to be notified when this item becomes available (account login required).
Contiguous US / Lower 48:
Free shipping applies to orders over $50 using our chosen carrier/method. Faster paid options are available at checkout.
Alaska, Hawaii & US Territories:
Free shipping applies to many—but not all—products. Enter your ZIP code in cart or upon checkout to confirm options and costs.
International:
International orders do not qualify for free shipping. Shipping, duties, brokerage, tariffs, and taxes are the customer’s responsibility. Some items may be restricted due to export, size, or manufacturer limitations.
- 110-pound (50 kg) Payload: All-metal precision internal construction makes this mount extremely strong and stable. The EQ8-R is a perfect fit for even the largest OTAs Sky-Watcher has to offer and is designed to thrive in your permanent or semi-permanent personal observatory.
- Belt-drive On Both Axes: Streamlined design and improved motor positioning allows for dual belt drives providing minimal backlash and significantly reduced periodic error which means smoother, more accurate tracking.
- Integrated Cable Management System: An integrated thru-mount cabling system contributes to the overall sleekness and efficiency while the internal USB hub, power, and serial ports eliminate cable drag and reduces the worry of cable snags.
- On-axis Renishaw Encoder:A Renishaw incremental 11.8 million tick encoder is installed on the RA axis of the EQ8-Rh, virtually eliminating periodic error and solidifying the status of the EQ8-Rh as an imminently precise, observatory-class mount for the advanced research astronomer or astrophotographer.
- Pier Tripod NOT included
Building on the legacy of Sky-Watcher’s popular EQ8 mount, the EQ8-Rh # S30712 introduces a variety of upgrades and enhancements that make observatory-class astrophotography easier than ever. Upgrades include a more streamlined design with balanced motor positioning, a sleek thru-mount cable management system and repositioned power hub with a more ergonomic feel to your setup and workflow. Also included are internal USB hub, larger saddle knobs for ease of use in cold weather, homing sensors to keep your mount oriented, physical hard stop to prevent cable snap, larger locking levers for ease of use, thread-on aircraft power connector for a secure connection, PC direct control, PPEC training for tack sharp images, and more!
Whisper-quiet dual belt drives greatly reduce periodic error while providing enhanced tracking and guiding. Gears measuring over eight inches in diameter help handle large payloads and provide smooth tracking. The fully realized cable management system eliminates cable drag and makes remote setups ridiculously convenient.
For users already familiar with previous Sky-Watcher mounts, the EQ8-R is a substantial upgrade, but with familiar features that will help dampen the learning curve. This is an observatory-class mount designed to be controlled PC Direct or even completely remote and yet, the EQ8-R can still be run by the tried-and-true SynScan V5 hand controller with a 42,000+ object database. Two large carrying handles make set up and takedown less awkward. Other features include a super sturdy adjustable portable pier tripod, D-style dovetail saddle, two 22-pound counterweights, DC power cord, and built-in USB PC control.
Features:
- The EQ8-R has an available optional polar scope available, making polar alignment quick and easy
- Cable management features four USB 3.0 ports, three 2.1mm power ports and three serial ports
- Rock-solid, all-metal construction delivers a staggering 110 pounds of payload capacity
Specifications:
General Mount Information:
- Mount Type: High-capacity motorized equatorial (EQ)
- Tripod: No Tripod Included
- GoTo: Yes
- Payload Capacity (lbs): 110
- Mount Head Height (head by itself): 19.5"
- Mount Head Weight (lbs): 56.8
- Mounting Saddle Type: D-style
- Power Type: DC11~16V, 3 amp
- Cable management: Four USB 3.0 ports, Three 2.1mm power ports, Three serial connections
- Polar Scope: Sold seperately
- Latitude Range (degrees): 10° to 65°
Computer/Drive System Information:
- Object Database: Complete Messier, NGC, IC and SAO catalogs, 25 user defined objects, total 42,900 objects
- Controller: SynScan hand controller, flash upgradeable, or PC direct
- Alignment Procedures: One-, two- and three-star alignment
- Slew Speeds: 1000x, 800x, 600x, 400x, 200x, 32x, 16x, 8x, 2x, 1x
- WiFi: Optional WiFi dongle
- GPS: Optional SynScan GPS sold seperately
- Included Weights: 22lbs (two)
- Motor Type: 0.9° hybrid stepper motor
- Drive System: Belt
Other Information
- Country of Manufacture: China
Building on the legacy of Sky-Watcher’s popular EQ8 mount, the EQ8-Rh # S30712 introduces a variety of upgrades and enhancements that make observatory-class astrophotography easier than ever. Upgrades include a more streamlined design with balanced motor positioning, a sleek thru-mount cable management system and repositioned power hub with a more ergonomic feel to your setup and workflow. Also included are internal USB hub, larger saddle knobs for ease of use in cold weather, homing sensors to keep your mount oriented, physical hard stop to prevent cable snap, larger locking levers for ease of use, thread-on aircraft power connector for a secure connection, PC direct control, PPEC training for tack sharp images, and more!
Whisper-quiet dual belt drives greatly reduce periodic error while providing enhanced tracking and guiding. Gears measuring over eight inches in diameter help handle large payloads and provide smooth tracking. The fully realized cable management system eliminates cable drag and makes remote setups ridiculously convenient.
For users already familiar with previous Sky-Watcher mounts, the EQ8-R is a substantial upgrade, but with familiar features that will help dampen the learning curve. This is an observatory-class mount designed to be controlled PC Direct or even completely remote and yet, the EQ8-R can still be run by the tried-and-true SynScan V5 hand controller with a 42,000+ object database. Two large carrying handles make set up and takedown less awkward. Other features include a super sturdy adjustable portable pier tripod, D-style dovetail saddle, two 22-pound counterweights, DC power cord, and built-in USB PC control.
Features:
- The EQ8-R has an available optional polar scope available, making polar alignment quick and easy
- Cable management features four USB 3.0 ports, three 2.1mm power ports and three serial ports
- Rock-solid, all-metal construction delivers a staggering 110 pounds of payload capacity
Specifications:
General Mount Information:
- Mount Type: High-capacity motorized equatorial (EQ)
- Tripod: No Tripod Included
- GoTo: Yes
- Payload Capacity (lbs): 110
- Mount Head Height (head by itself): 19.5"
- Mount Head Weight (lbs): 56.8
- Mounting Saddle Type: D-style
- Power Type: DC11~16V, 3 amp
- Cable management: Four USB 3.0 ports, Three 2.1mm power ports, Three serial connections
- Polar Scope: Sold seperately
- Latitude Range (degrees): 10° to 65°
Computer/Drive System Information:
- Object Database: Complete Messier, NGC, IC and SAO catalogs, 25 user defined objects, total 42,900 objects
- Controller: SynScan hand controller, flash upgradeable, or PC direct
- Alignment Procedures: One-, two- and three-star alignment
- Slew Speeds: 1000x, 800x, 600x, 400x, 200x, 32x, 16x, 8x, 2x, 1x
- WiFi: Optional WiFi dongle
- GPS: Optional SynScan GPS sold seperately
- Included Weights: 22lbs (two)
- Motor Type: 0.9° hybrid stepper motor
- Drive System: Belt
- 110-pound (50 kg) Payload: All-metal precision internal construction makes this mount extremely strong and stable. The EQ8-R is a perfect fit for even the largest OTAs Sky-Watcher has to offer and is designed to thrive in your permanent or semi-permanent personal observatory.
- Belt-drive On Both Axes: Streamlined design and improved motor positioning allows for dual belt drives providing minimal backlash and significantly reduced periodic error which means smoother, more accurate tracking.
- Integrated Cable Management System: An integrated thru-mount cabling system contributes to the overall sleekness and efficiency while the internal USB hub, power, and serial ports eliminate cable drag and reduces the worry of cable snags.
- On-axis Renishaw Encoder:A Renishaw incremental 11.8 million tick encoder is installed on the RA axis of the EQ8-Rh, virtually eliminating periodic error and solidifying the status of the EQ8-Rh as an imminently precise, observatory-class mount for the advanced research astronomer or astrophotographer.
- Pier Tripod NOT included
Building on the legacy of Sky-Watcher’s popular EQ8 mount, the EQ8-Rh # S30712 introduces a variety of upgrades and enhancements that make observatory-class astrophotography easier than ever. Upgrades include a more streamlined design with balanced motor positioning, a sleek thru-mount cable management system and repositioned power hub with a more ergonomic feel to your setup and workflow. Also included are internal USB hub, larger saddle knobs for ease of use in cold weather, homing sensors to keep your mount oriented, physical hard stop to prevent cable snap, larger locking levers for ease of use, thread-on aircraft power connector for a secure connection, PC direct control, PPEC training for tack sharp images, and more!
Whisper-quiet dual belt drives greatly reduce periodic error while providing enhanced tracking and guiding. Gears measuring over eight inches in diameter help handle large payloads and provide smooth tracking. The fully realized cable management system eliminates cable drag and makes remote setups ridiculously convenient.
For users already familiar with previous Sky-Watcher mounts, the EQ8-R is a substantial upgrade, but with familiar features that will help dampen the learning curve. This is an observatory-class mount designed to be controlled PC Direct or even completely remote and yet, the EQ8-R can still be run by the tried-and-true SynScan V5 hand controller with a 42,000+ object database. Two large carrying handles make set up and takedown less awkward. Other features include a super sturdy adjustable portable pier tripod, D-style dovetail saddle, two 22-pound counterweights, DC power cord, and built-in USB PC control.
Features:
- The EQ8-R has an available optional polar scope available, making polar alignment quick and easy
- Cable management features four USB 3.0 ports, three 2.1mm power ports and three serial ports
- Rock-solid, all-metal construction delivers a staggering 110 pounds of payload capacity
Specifications:
General Mount Information:
- Mount Type: High-capacity motorized equatorial (EQ)
- Tripod: No Tripod Included
- GoTo: Yes
- Payload Capacity (lbs): 110
- Mount Head Height (head by itself): 19.5"
- Mount Head Weight (lbs): 56.8
- Mounting Saddle Type: D-style
- Power Type: DC11~16V, 3 amp
- Cable management: Four USB 3.0 ports, Three 2.1mm power ports, Three serial connections
- Polar Scope: Sold seperately
- Latitude Range (degrees): 10° to 65°
Computer/Drive System Information:
- Object Database: Complete Messier, NGC, IC and SAO catalogs, 25 user defined objects, total 42,900 objects
- Controller: SynScan hand controller, flash upgradeable, or PC direct
- Alignment Procedures: One-, two- and three-star alignment
- Slew Speeds: 1000x, 800x, 600x, 400x, 200x, 32x, 16x, 8x, 2x, 1x
- WiFi: Optional WiFi dongle
- GPS: Optional SynScan GPS sold seperately
- Included Weights: 22lbs (two)
- Motor Type: 0.9° hybrid stepper motor
- Drive System: Belt
Other Information
- Country of Manufacture: China
Sky-Watcher EQ8-Rh Observatory-Class Computerized GoTo Telescope Mount Head with Counterweights (No Pier Tripod)
