William Optics Adjustable Field Flattener 61A for Z61 Telescope
- This is a special order item.
- Before you place your order, please contact us for an estimated shipping date. We will order it directly from the manufacturer and ship it to you as soon as it arrives at our warehouse.
- Transit time varies by location.
Stock count is accurate & shown in real time.
- This item is out of stock.
- Sign up for back-in-stock alerts to be notified when this item becomes available (account login required).
- This item is out of stock.
- Sign up for back-in-stock alerts to be notified when this item becomes available (account login required).
Contiguous US / Lower 48:
Free shipping applies to orders over $50 using our chosen carrier/method. Faster paid options are available at checkout.
Alaska, Hawaii & US Territories:
Free shipping applies to many—but not all—products. Enter your ZIP code in cart or upon checkout to confirm options and costs.
International:
International orders do not qualify for free shipping. Shipping, duties, brokerage, tariffs, and taxes are the customer’s responsibility. Some items may be restricted due to export, size, or manufacturer limitations.
Dedicated flattener by William Optics optimized for use with their Z61 Apo telescopes. NOT for use with their Star 61 guidescope.
On the telescope side, this flattener has a male M54 thread for direct connection to the focuser drawtube (this requires you to unscrew the 2" eyepiece holder ring on the telescope to expose the M54 female thread inside the drawtube).
On the camera side, the flattener has a male M48x0.75 thread. You can use your Canon or Nikon or other DSLR directly with the use of an optional M48 camera-specific T-ring (sold separately). Please note that this cannot be used with the smaller 42mm T rings.
Note that this item does not have a conventional 2" nosepiece or eyepiece holder. It is for direct connection of a camera to the William Optics Z61 scope only.
A very neat fature of this item is that a rotator/camera angle adjuster is built into the mechanism of this item, making a separate rotator unnecessary.
True 1:1 flattener with no reduction.
Compatibility:
- Zenithstar 61
- Back Focus: 67.7mm
- Adjust Distance: 12.9mm
- Image Circle: ∅43mm
Specifications:
- Lens Type: 2 Groups 2 Elements
- Length: Flattener 39.5 mm + Rotator/Adapter 19 mm
- Telescope Thread: M54 x 0.75 x 5 mm
- T-mount Thread: M48 x 0.75 x 4 mm
- T-mount Supported: Canon EF, RF; Nikon F, Z; Sony E; Pentax K; MFT (M4/3); FUJI X
- Camera Format: > Full Frame
- Weight: 272.8 g / 0.6lbs
Other Information
- Country of Manufacture: Taiwan
